VBA for Excel : Membuat TTS Interaktif dengan Excel

Pada posting ini disajikan listing program untuk membuat TTS Interaktif dengan Excel.

Kotak TTS :

gbr1

Pertanyaan TTS :

gbr2



Listing Program agar TTS Excel anda menjadi Interaktif :

ttribute VB_Name = “Module1”
Sub reset()
‘KOSONGKAN CELL
Dim kotakClear As Variant

kotakClear = Array(Range(“B4:K4”), Range(“B6,E6,G6,I6,K6,L6”), Range(“B8:E8,G8:I8,K8”), _
Range(“B10,D10:G10,I10:L10”), Range(“B12,D12,F12,H12,J12,L12”), Range(“B14:E14,G14:J14,L14”), _
Range(“C16,E16:G16,I16:L16”), Range(“B18,C18,E18,G18,I18,L18”), Range(“C20:L20”))

For i = 0 To 8
With kotakClear(i)
.Value = “”
.Font.Color = RGB(0, 0, 0)
End With
Next

Worksheets(“TTSNo2”).Shapes(“Button 2”).Visible = True

End Sub
Sub periksa()

Dim kunci1 As Variant
Dim kunci2 As Variant
Dim kotak As Variant
Dim Jbenar As Integer
Dim nilaiTTS As Double

‘KUNCI JAWABAN DENGAN HURUF KAPITAL
kunci1 = Array(“P”, “O”, “L”, “I”, “K”, “L”, “I”, “N”, “I”, “K”, _
“A”, “R”, “A”, “U”, “U”, “U”, _
“T”, “A”, “L”, “I”, “K”, “A”, “R”, “D”, _
“U”, “A”, “T”, “A”, “U”, “I”, “K”, “A”, “N”, _
“N”, “I”, “S”, “R”, “A”, “O”, _
“G”, “U”, “N”, “A”, “S”, “I”, “A”, “L”, “N”, _
“F”, “M”, “A”, “U”, “S”, “A”, “I”, “S”, _
“M”, “U”, “A”, “A”, “I”, “E”, _
“K”, “A”, “L”, “I”, “M”, “A”, “N”, “T”, “A”, “N”)
‘KUNCI JAWABAN DENGAN HURUF KECIL
kunci2 = Array(“p”, “o”, “l”, “i”, “k”, “l”, “i”, “n”, “i”, “k”, _
“a”, “r”, “a”, “u”, “u”, “u”, _
“t”, “a”, “l”, “i”, “k”, “a”, “r”, “d”, _
“u”, “a”, “t”, “a”, “u”, “i”, “k”, “a”, “n”, _
“n”, “i”, “s”, “r”, “a”, “o”, _
“g”, “u”, “n”, “a”, “s”, “i”, “a”, “l”, “n”, _
“f”, “m”, “a”, “u”, “s”, “a”, “i”, “s”, _
“m”, “u”, “a”, “a”, “i”, “e”, _
“k”, “a”, “l”, “i”, “m”, “a”, “n”, “t”, “a”, “n”)
‘KOTAK YANG DIGUNAKAN UNTUK ISIAN TTS
kotak = Array(Range(“B4”), Range(“C4”), Range(“D4”), Range(“E4”), Range(“F4”), Range(“G4”), Range(“H4”), Range(“I4”), Range(“J4”), Range(“K4”), _
Range(“B6”), Range(“E6”), Range(“G6”), Range(“I6”), Range(“K6”), Range(“L6”), _
Range(“B8”), Range(“C8”), Range(“D8”), Range(“E8”), Range(“G8”), Range(“H8”), Range(“I8”), Range(“K8”), _
Range(“B10”), Range(“D10”), Range(“E10”), Range(“F10”), Range(“G10”), Range(“I10”), Range(“J10”), Range(“K10”), Range(“L10”), _
Range(“B12”), Range(“D12”), Range(“F12”), Range(“H12”), Range(“J12”), Range(“L12”), _
Range(“B14”), Range(“C14”), Range(“D14”), Range(“E14”), Range(“G14”), Range(“H14”), Range(“I14”), Range(“J14”), Range(“L14”), _
Range(“C16”), Range(“E16”), Range(“F16”), Range(“G16”), Range(“I16”), Range(“J16”), Range(“K16”), Range(“L16”), _
Range(“B18”), Range(“C18”), Range(“E18”), Range(“G18”), Range(“I18”), Range(“L18”), _
Range(“C20”), Range(“D20”), Range(“E20”), Range(“F20”), Range(“G20”), Range(“H20”), Range(“I20”), Range(“J20”), Range(“K20”), Range(“L20”))

‘PERIKSA JAWABAN DENGAN KUNCI
Jbenar = 0

For i = 0 To 71
If kotak(i).Text = kunci1(i) Or kotak(i).Text = kunci2(i) Then
With kotak(i)
.Font.Color = RGB(0, 0, 255)
End With
Jbenar = Jbenar + 1
Else
With kotak(i)
.Font.Color = RGB(255, 0, 0)
End With
Jbenar = Jbenar + 0
End If
Next
nilaiTTS = Round((Jbenar / 72) * 100, 2)

If nilaiTTS >= 80 Then
UserForm1.Label1.Caption = nilaiTTS
UserForm1.Show
Else
UserForm2.Label1.Caption = nilaiTTS
UserForm2.Show
End If
Worksheets(“TTSNo2”).Shapes(“Button 2”).Visible = False
End Sub

Sub kareem()
UserForm3.Show
End Sub



download : TTS Excel Interaktif (file xlsm)

Maple by Example : Program Linear

quotesPada seri posting Maple by Exampe ini, akan disajikan contoh-contoh penyelesaian soal-soal matematika SMA menggunakan teknologi “Computer Algebra Systems”, dalam hal ini software yang digunakan adalah Maple.

Contoh 1 :

contohProglinear_01

Penyelesaian dengan Maple :

jawabProglinear_01

Contoh 2 :

contohProglinear_02

Penyelesaian dengan Maple :

jawabProglinear_02

Contoh 3 :

contohProglinear_03

Penyelesaian dengan Maple :

jawabProglinear_03

Maple by Example : Notasi Sigma

quotesPada seri posting Maple by Exampe ini, akan disajikan contoh-contoh penyelesaian soal-soal matematika SMA menggunakan teknologi “Computer Algebra Systems”, dalam hal ini software yang digunakan adalah Maple.

Contoh 1 :

ContohNotasiSigma_01

Penyelesaian dengan Maple :

jawabNotasiSigma_01

Contoh 2 :

ContohNotasiSigma_02

Penyelesaian dengan Maple :

jawabNotasiSigma_02
